Description
Storage
Solid State Capacity | 512 GB |
Drive Size | M.2 2280 |
Memory Type | SSD |
Memory Size | 512 GB |
Memory Package | 3D TLC |
Performance
Read Speed | Up to 2,100 MB/s |
Write Speed | Up to 1,400 MB/s |
4K Random Read (AS SSD) | Up to 250,000 IOPS |
4K Random Write (AS SSD) | Up to 240,000 IOPS |
Data Storage Life | 300 TBW |
Mean Time Between Failure (MTBF) | 2,000,000 Hours |
Interfaces/Ports
Interface Type | PCIe 3.0 x4 NVMe |
System Requirements
System Requirements | 1 x Free PCIe 3.0 x2 |
Electrical
Electrical Power Consumption | 0.33 W |
Electrical Power Consumption Standby | 0.14 W |
Environmental
Operating Temperature | 0 to 70 °C |
Storage Temperature | -40 to 85 °C |
Shock (Operating) | 1500 g |
Physical
Form Factor | Drive |
Pack Quantity | 1 |
Enclosure type | Internal |
Case Colour | Black |
Width | 22 mm |
Depth | 80 mm |
Height | 2.15 mm |
Weight | 8 g |
Warranty
Warranty | 5 Years |
Key Features
Disk Capacity | 512 GB |
Main Colour | Black |
Storage Capacity | 512 GB |
Solid State Drive | Yes |
Disk Form Factor | M.2 2280 |
Read IOPS (4K) | 250000 |
Write IOPS (4K) | 240000 |
