Description
Specification
- Form Factor: ATX
- Series: Corsair TX-M
- Modular: Semi Modular
- Compatability: ATX12V v2.4
- #Hide#Wattage Range: 600 – 660W
- Wattage: 650 W
- Connectors: 2 x 4+4-pin CPU +12V (EPS)
4 x 4-pin Molex
4 x 6+2-pin PCIe
6 x SATA - Rail Design: Single Rail
- AC Input: 100-240V
- Fan Type: 120mm rifle bearing fan
- Fan Bearing: Rifle Bearing
- Noise: Low-noise operation
- 80+ Certification: 80+ Gold
- Efficiency: Up to 90%
- MTBF: “100000 hours”
- Features: See Overview
- Weight/Dimensions: 1.53 kg
140 x 150 x 86 mm - Package Weight: 2.4160 kg
Special Technology
OVP (Over Voltage)
UVP (Under Voltage)
SCP (Short Circuit)
OTP (Over Temp)
OPP (Over Power)
UVP (Under Voltage)
SCP (Short Circuit)
OTP (Over Temp)
OPP (Over Power)
Protections
OVP (Over Voltage)
UVP (Under Voltage)
SCP (Short Circuit)
OTP (Over Temp)
OPP (Over Power)
UVP (Under Voltage)
SCP (Short Circuit)
OTP (Over Temp)
OPP (Over Power)
